The OSA-25PL is a versatile X-ray generator engineered for NDT laboratories in the oil and gas sector that demand advanced imaging capabilities and flexible operational parameters. It provides higher penetration performance and expanded exposure settings, enabling detailed radiographic analysis of pipeline welds, branch connections, and a variety of component geometries commonly encountered in hydrocarbon processing and transportation infrastructure.
The unit is designed for demanding inspection workflows where precision, repeatability, and image clarity are essential for maintaining pipeline integrity and safety compliance across Middle Eastern operations.
| Model Technical Specifications: | ||
| X-ray generator model | OSA-25PL | |
| X-ray tube model (material) | XT2 (B) ceramic | |
| Radiation beam (directed) | 40º × 360º | |
| Tube voltage (kV) | 80 ÷ 250 | |
| Tube current (mA) | 4 to 5 | |
| Focal spot (mm) | 1.0 × 2.4 | |
| Cooling | air | |
| Power supply | AC 190V–260V / 50Hz | |
| Power (kW) | 2.0 | |
| Weight (kg) | X-ray radiation generator | 20 |
| Control unit | 9 | |
| Dimensions (mm) | X-ray radiation generator | Ø 270 × 570 with handles |
| Control unit | 290 × 165 × 300 | |
| Exposure delay time (min) | 0 ÷ 3 (step 6 seconds) | |
| Penetrating capacity Fe (mm) Agfa | AGFA: D7 = 36, F8 (NDT1200) ≥ 50 | |
| Operating temperature range | -30ºC ~ +40ºC | |
| OSA-25PL Delivery Set: | |
| X-ray radiation generator 250 kV | 1 |
| Control unit / Remote control with 50 m range | 1/1 |
| Frost-resistant interconnection cable 20 m | 1 |
| Power cable 10 m | 1 |
| Grounding cable 5 m + steel spike | 1 |
| Generator handle set (4 pcs) | 1 |
| Magnetic signal lamp 24V + charger | 1 |
| Black bag / Tightening strap 3 m | 1/1 |
| Transport case | 2 |
| Passport / Operation manual | 1/1 |
| Warranty card (12 months) | 1 |
| Customs Union Declaration of Conformity | 1 |
The generator’s design allows for inspection of hard-to-reach welded joints, such as elbows, tees, reducers, flanges, and others.
The OSA series generators have a ceramic X-ray tube made of German materials with an opening angle of 40 to 60, which allows for inspection of a welded joint in just three exposures.
The use of SF-6 gas as an insulator in the equipment design allows for work in any plane.
The equipment is designed for a wide range of operating temperatures—from -40°C to +50°C.
The equipment is assembled from high-quality German and Japanese components and has a modular design. As a result, you receive fast and high-quality service. Components are always in stock.
and we will prepare a commercial proposal for you tailored to your specific case.
